The ledge everyone calls a sill

Ask a homeowner where a plant or a candle sits at a window, and the answer is the sill. Ask a carpenter, and the answer is the stool. The difference is not pedantry. The sill is the sloped surface at the bottom of the window frame itself, designed to shed water to the outside. The stool is the flat board that sits on top of the inner edge of the rough opening, across the bottom of the window, and projects into the room. Below the stool, mounted on the wall, is a narrower board called the apron. Together, stool and apron form the finished base of an interior window opening.

How a stool is shaped

A stool is a single board with a profile cut into its front edge and notches cut into its back corners. The profile is usually a rounded or slightly beveled nose, similar to the edge of a stair tread, and it makes the ledge comfortable to touch and easy to clean. The notches are called ears, or horns. The stool is wider than the opening, so each end extends sideways past the casing. The extra length is the horn, and the notch lets the board slide past the side casing and tuck against the wall.

Because the stool must fit snugly against the window frame at the back and the wall at each end, it is scribed rather than simply measured. The carpenter holds the board in place, traces the shape of the frame and the wall onto it with a pencil, and cuts to the line. Walls are rarely perfectly flat or plumb, and a scribed stool follows their irregularities so the joint is tight.

Where the stool gets its support

A stool is not decoration that floats in place. It carries weight, because people lean on it, set objects on it and sometimes sit on it. It must rest on something solid, and the support comes from several places.

• The rough framing below the window, which is a horizontal board in the wall called the rough sill.
• Shims placed between the stool and the rough sill, which fill small gaps and level the board.
• The window frame at the back, where the stool rests against or slightly beneath the inner lip of the frame.
• The apron beneath it, which is nailed to the framing and to the underside of the stool.

Without this support, a stool can sag in the middle or tilt toward the room. The result is a visible gap along the back edge where dust and moisture collect.

What the apron does

The apron is a narrower board with a decorative profile, mounted flat on the wall below the stool. Its top edge touches the underside of the stool, and its length typically matches the distance between the outer edges of the side casings. It serves several purposes. It hides the rough edge of the wall finish where it meets the bottom of the opening. It provides a place to nail upward into the stool for extra support. It also supplies visual weight at the base of the window, mirroring the head casing at the top.

Aprons come in many profiles, from plain flat boards to those with a cove or a bead on the lower edge. In a house with matching trim, the apron's profile follows the style of the casing. It should be nailed into solid framing, not only into drywall, so that it does not drift away from the stool.

Profiles and styles

The choice of stool and apron profile helps decide whether a room feels traditional or modern. A thick, deeply rounded stool with a substantial apron beneath it suggests a craftsman or classic style. A thin, squared off ledge with no apron, or a flat board in the same width as the casing, suggests a contemporary look. Some houses have no stool at all, using a picture frame arrangement where casing wraps all four sides and the window stands out from the wall.

Depth also varies. A deep stool, often called a window seat or shelf, projects several inches and can hold books or plants. A shallow one projects just enough to cover the edge of the opening. The thickness of the wall decides how much room is available, and walls with thicker framing or added insulation often produce deeper stools.

Materials that suit each room

Wood is the classic material. Poplar, pine and oak are common, and each takes paint or stain differently. Solid wood is best for stools that will be stained, and primed finger jointed boards are common for painted ones. Moisture is the main enemy of wood stools, because they sit at the spot where condensation forms on the glass and where rain can get past an open window. In kitchens and bathrooms, where moisture is frequent, many people choose engineered materials such as cellular PVC, which does not swell, or stone and tile ledges, which are impervious to water.

Whatever the material, every edge of a wood stool, including the underside and the end grain, should be primed before installation. The face is the part people see, but the underside is the part that touches a damp cavity.

Replacing a worn or damaged stool

Stools take the most punishment of any piece of trim. They collect condensation drips, sun fading and dents. A stool that is stained dark, softened by repeated moisture, split along its length or visibly sagging should be replaced. The process involves a few clear steps.

1. Score the paint line where the stool meets the wall and where it meets the casing.
2. Remove the apron first, since it holds the stool from below.
3. Gently pry the stool upward, working from the middle to avoid splitting the horns.
4. Check the framing underneath for moisture damage and correct it.
5. Use the old stool as a template for the new one, then scribe to fit.
6. Shim, nail, caulk and paint the new stool and apron.

The old board is useful because it already shows the length, the notch positions and the profile. Trace it onto the new stock before cutting, then adjust as needed for any changes to the opening.

Sealing the stool against water

A small bead of flexible, paintable caulk along the back edge of the stool, where it meets the window frame, prevents water running down the glass from entering the gap. The same caulk fills the narrow line where the horns meet the wall. A very small gap beneath the stool, at its back, is better left unsealed in some designs so that any moisture can escape. The window frame's own sloped sill is the real water defense, and the stool stays dry as long as the frame performs.

If the stool is regularly wet, look for the cause. Condensation, a failing seal, a roof leak or a gap in exterior flashing can all send water to this spot. Repainting does not fix any of them.

Details that make the finished ledge last

A few habits give the stool a long life. Use stainless or coated finish nails, which resist rust where moisture is likely. Set nail heads below the surface and fill them, so rust stains do not bleed through paint. Choose a durable semi gloss paint that can be wiped. Keep plants in saucers rather than directly on the surface, since a constantly damp pot lifts paint and darkens wood.

Seen as a whole, the stool and apron are simple, but they illustrate the larger lesson of window trim: a small piece that looks decorative carries load, sheds moisture and finishes a joint. Choosing it with the same care as the glass leads to a better window overall.
